Description
PROMOTION SALE!
Heavy-duty steel frame construction with handle operated hydraulic pump unit. Screw adjustable ram and adjustable work area with removable tray. Winch assisted press table adjustment. Frame head fitted with ram pressure gauge. Storage for press pins included in frame. Supplied with press pins, flat pressing plate/V-blocks.
• Heavy-duty steel frame construction with handle operated hydraulic pump unit.
• Screw adjustable ram and adjustable work area with removable tray.
• Frame head fitted with ram pressure gauge.
• Winch assisted press table adjustment.
• Storage for press pins included in frame.
• Supplied with press pins, flat pressing plate/V-blocks.
• 5 Year guarantee*.
• This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Specifications
| Model No | PPF20S |
| Bench or Floor Mounting: | Floor |
| Brand: | Viking |
| Capacity: | 20 Tonne |
| Gauge Included: | Yes |
| Lateral Ram Travel: | n/a |
| Maximum Height – Ram to Table: | 850mm |
| Minimum Height – Ram to Table: | 25mm |
| Nett Weight: | 121.4kg |
| Operating Table Width: | 540mm |
| Overall Height: | 1800mm |
| Ram Diameter: | Ø84.2mm |
| Ram Stroke: | 220mm |
| Screw Extension: | 75mm |
| Table Aperture: | 150mm |
| Type: | Floor |
| Working Table Depth: | 166mm |
| Working Table Width: | 710mm |
Documents
| Material Safety Data Sheet | View/Download |
| Parts Diagrams | View/Download |
| Instructions | View/Download |
