WOSP LMDMOR8-6V 6V 50A Dynamo-Style Alternator for Morris 8 & Austin 10/4 (1933)

Description

Applications

• Morris Eight / Morris 8 (Series 1 & Series 2) (with provision for fitting original cooling fan) C45V 228269 (6V) / C45YV 22448 / C45N 228306 (12V)
• Austin 10/4 (1933)

6V and 24V units are not available as self-exciting (single wire hook-up).

Dynators, unlike the dynamos they are replacing are polarity sensitive.

90A version – This increase in output is yielded at higher rpm therefore ‘HO’ units often need 2-3 times more speed for output and cooling. They are considerably less efficient than a standard unit at low rpm.

‘SD’ (super-duty) Dynator (95A) gives high output at low RPM but body Ø increases to 5″.

To make a super-duty (SD) unit even higher output by re-winding and uprating (170A) select the ‘SD-HO’ version. Operational speeds need to increase slightly.

Unless the part number is superseded with suffix -LS or -HO, then work on the basis that the Dynator has a turn on speed of 1250rpm.

Some units spin at 1:1 or less than engine speed, therefore low or no charge at idle E.G. ALVIS / BEN001 / FER001 / MGM001 / RIL.
