WOSP LMDMGMO001+VE-6V 6V 50A Dynamo-Style Alternator for MG Models & Morris Minor OHV – Positive Ground

Description

Applications

• MG F, MG M, MG J , MG K , MG L, and Some MG P types (Replacing CAV/Rotax DDS6 / DDS10 / DDS14 / B27160 / B15544 / B423856 Dynamo / Generator)
• Morris Minor OHC (Replacing CAV/Rotax DDS6 / DDS10 / DDS14 / B27160 / B15544 Dynamo / Generator)
• MG PB 1936 (Replacing CAV/Rotax DDS6 / DDS10 / DDS14 / B27160 / B15544 Dynamo / Generator)

6V and 24V units are not available as self-exciting (single wire hook-up).

Dynators, unlike the dynamos they are replacing are polarity sensitive.

90A version – This increase in output is yielded at higher rpm therefore ‘HO’ units often need 2-3 times more speed for output and cooling. They are considerably less efficient than a standard unit at low rpm.

‘SD’ (super-duty) Dynator (95A) gives high output at low RPM but body Ø increases to 5″.

To make a super-duty (SD) unit even higher output by re-winding and uprating (170A) select the ‘SD-HO’ version. Operational speeds need to increase slightly.

Unless the part number is superseded with suffix -LS or -HO, then work on the basis that the Dynator has a turn on speed of 1250rpm.

Some units spin at 1:1 or less than engine speed, therefore low or no charge at idle E.G. ALVIS / BEN001 / FER001 / MGM001 / RIL.
