Description
Approved to EU and UK Lifting Gear Regulations. This hoist is intended for use where a suitable support facility exists. Support brackets are included with the equipment. The support bar is not included.
• Approved to EU and UK Lifting Gear Regulations.
• This hoist is intended for use where a suitable support facility exists.
• Support brackets are included with the equipment.
• N.B. Support bar is not included.
Specifications
| Model No | PH250 |
| Brand: | Sealey |
| Capacity (Double Cable): | 250kg |
| Capacity (Single Cable): | 125kg |
| Current: | 2.2A |
| Duty Cycle: | S3 |
| Group of Mechanisms: | M1 |
| Insulating Grade: | B |
| IP Rating: | IP54 |
| Lift Height (Double Cable): | 6m |
| Lift Height (Single Cable): | 12m |
| Lift Speed (Maximum): | 8m/min |
| Minimum Rope Tensile Strength: | 1870N/mm² |
| Motor Power: | 500W |
| Nett Weight: | 9.6kg |
| Rope Diameter: | 3mm |
| Voltage: | 230V~50Hz |
| Work Rate: | S3 |
Documents
| Parts Diagrams | View/Download |
| Instructions | View/Download |
